ECEMilitary 4×4 UTV 1000cc Manufacturer Gas/Electric 2-Seater Trailer
The Military 4×4 UTV Trailer for the Two Seater Jaguar 1000 is engineered to meet rugged transportation demands, offering both the powerful Jaguar 1000 (1000cc water-cooled engine, manual 5-speed transmission, 130N·m torque) and the Jaguar 1000EV (15kW/30kW electric motor, up to 260km range, 550kg cargo load). Both variants feature a robust 4×4 drivetrain, dual independent suspension, front and rear disc brakes, and EEC certification, ensuring safety and reliability for global deployment.
Military transportation
Logistics support
Mining operations
Emergency rescue
Engineering construction
Disaster relief
| Model | Jaguar 1000 | Jaguar 1000EV |
|---|---|---|
| Category | Engine | Electric Version |
| Engine | 1000cc CF Motor | Rated Power 15kw, Peak 30kw |
| Cooling System | Water Cooling | N/A (Electric) |
| Ignition | EFI | N/A (Electric) |
| Transmission | Manual, 5-speed | N/A (Electric) |
| Drive System | 4X4 | 4X4 |
| Suspension | F&R Dual Independent | F&R Dual Independent |
| Brakes | F&R Disc Brake | F&R Disc Brake |
| Tires | F: ATV 25×8-12; R: ATV 25×10-12 | N/A |
| Wheelbase | 1840 mm | N/A |
| Power Output | Rated 15kW / Peak 30kW | Rated Power: Aligned with battery specs |
| Max Torque | 130 N.m | N/A |
| Max Speed | N/A | 50 km/h |
| Max Range | N/A | 130 km / 260 km (battery-dependent) |
| Cargo Bed Load Capacity | N/A | 550 kg |
| Ground Clearance | 310 mm | 310 mm |
| Dimensions | 3520 x 1550 x 2065 mm | 3580 x 1550 x 2065 mm |
| Net Weight (NW) | 665 kg | 1100 kg |
| Certification | EEC | EEC |
| Unique Features | Manual control, high torque | Electric powertrain, cargo load focus |
